System Sealed
Woofer count 1
Woofer size 15" (381 mm)
Woofer type Coated paper cone
Passive Unit 1
Passive Unit size 15" (381 mm)
Passive Unit type Coated paper cone
- COMPONENTS
- PERFORMANCE
- DIMENSIONS
Amplifer type Class D with Analog Preamp Stage
Power handing 100W RMS / 2000W Peak
Features Volume, Lowpass, Phase, Auto Power
Phase 0-180 degrees adjustable
Frequency response 24 Hz - 140 Hz
Power handing 100W RMS / 2000W Peak
Features Volume, Lowpass, Phase, Auto Power
Phase 0-180 degrees adjustable
Frequency response 24 Hz - 140 Hz
Cabinet specifications (H × W × D) 515 × 440 × 543 mm
Frameless grill dimensions (H × W × D) 465 × 440 × 18 mm
Product weight (each) 36.5 kg
Shipping weight (each) 41.3 kg
Grill material Cloth grille with pin/cup retention
Frameless grill dimensions (H × W × D) 465 × 440 × 18 mm
Product weight (each) 36.5 kg
Shipping weight (each) 41.3 kg
Grill material Cloth grille with pin/cup retention
