System Sealed
Woofer count 1
Woofer size 10" (254 mm)
Woofer type Coated paper cone
Passive Unit 1
Passive Unit size 10" (254 mm)
Passive Unit type Coated paper cone
- COMPONENTS
- PERFORMANCE
- DIMENSIONS
Amplifer type Class D with Analog Preamp Stage
Power handing 400W RMS / 800W Peak
Features Volume, Lowpass, Phase, Auto Power
Phase 0-180 degrees adjustable
Frequency response 30 Hz - 140 Hz
Power handing 400W RMS / 800W Peak
Features Volume, Lowpass, Phase, Auto Power
Phase 0-180 degrees adjustable
Frequency response 30 Hz - 140 Hz
Cabinet specifications (H × W × D) 396 × 355 × 410 mm
Frameless grill dimensions (H × W × D) 366 × 355 × 15 mm
Product weight (each) 19.3 kg
Shipping weight (each) 22.1 kg
Grill material Cloth grille with pin/cup retention
Frameless grill dimensions (H × W × D) 366 × 355 × 15 mm
Product weight (each) 19.3 kg
Shipping weight (each) 22.1 kg
Grill material Cloth grille with pin/cup retention
