Tweeter count 1
Tweeter size 1.75" (45 mm)
Tweeter type compression
Woofer count 1
Woofer size 8" (203 mm)
Woofer type paper cone
- CM 8T
Cabinets are 2-way vented-box systerm compact design. Easy-mount installation, On-wall and In-wall.
The woofer design includes a large magnet, large voice coil with heavy-gauge wire. The rigid and specially coated cone, provides high output and realistic dynamics.
1.75"compression Tweeter, Composite material dome provides more natural sound. Unique lotus leaf shaped horn provides a wider sound stage.
The CM8T can be installed behind a perforated video screen or cabinet grille cloth in most installations. It features a Screen Compensation Switch to accommodate installation in this environment.
The woofer design includes a large magnet, large voice coil with heavy-gauge wire. The rigid and specially coated cone, provides high output and realistic dynamics.
1.75"compression Tweeter, Composite material dome provides more natural sound. Unique lotus leaf shaped horn provides a wider sound stage.
The CM8T can be installed behind a perforated video screen or cabinet grille cloth in most installations. It features a Screen Compensation Switch to accommodate installation in this environment.
- COMPONENTS
- PERFORMANCE
- DIMENSIONS
Power handing 200W RMS / 800W Peak
Impedance (nominal) 8 ohm
Sensitivity (dB @ 2.83V, 1 m) 93 dB
Nominal Coverage 60°(V) × 90°(H)
Frequency response 65 Hz - 20k Hz
Impedance (nominal) 8 ohm
Sensitivity (dB @ 2.83V, 1 m) 93 dB
Nominal Coverage 60°(V) × 90°(H)
Frequency response 65 Hz - 20k Hz
Cabinet specifications (H × W × D) 454 × 290 × 198 mm
Frameless grill dimensions (H × W× D) 454 × 290 × 15 mm
Product weight (each) 12.2 kg
Shipping weight (each) 13.5 kg
Grill material Cloth grille with pin/cup retention
Frameless grill dimensions (H × W× D) 454 × 290 × 15 mm
Product weight (each) 12.2 kg
Shipping weight (each) 13.5 kg
Grill material Cloth grille with pin/cup retention
