System Vented
Woofer count 1
Woofer size 12" (305 mm)
Woofer type Coated paper cone
- C 12-IW
The grill is removable, the vented box system design is 1" MDF. The port is designed with a flared horn shape to reduce the noise produced by the air flow.
In order to extend the low frequency response, The precise length tuned port provides deep, extended low frequency response.
Built in 300W, class D amplifier. Full energy storage, and restores freely when a large dynamic signal is applied. The volume and frequency crossover point can be adjusted continuously, and a phase 0 degree /180 degree switch is provided. High and low level input, 0.5W standby low power consumption without signal automatic standby mode, effective management of power amplifier.
The 12" driver uses a high density composite cone, and the surface is coated in a special process to enhance the rigidity and ensure the cone movement without distortion.
Ultra thin design supports In-wall installation.
In order to extend the low frequency response, The precise length tuned port provides deep, extended low frequency response.
Built in 300W, class D amplifier. Full energy storage, and restores freely when a large dynamic signal is applied. The volume and frequency crossover point can be adjusted continuously, and a phase 0 degree /180 degree switch is provided. High and low level input, 0.5W standby low power consumption without signal automatic standby mode, effective management of power amplifier.
The 12" driver uses a high density composite cone, and the surface is coated in a special process to enhance the rigidity and ensure the cone movement without distortion.
Ultra thin design supports In-wall installation.
- COMPONENTS
- PERFORMANCE
- DIMENSIONS
Amplifer type Class D with Analog Preamp Stage
Power handing 300W RMS / 600W Peak
Features Volume, Lowpass, Phase, Auto Power
Phase 0-180 degrees adjustable
Frequency response 28 Hz - 140 Hz
Power handing 300W RMS / 600W Peak
Features Volume, Lowpass, Phase, Auto Power
Phase 0-180 degrees adjustable
Frequency response 28 Hz - 140 Hz
Cabinet specifications (H × W × D) 480 × 750 × 258 mm
Frameless grill dimensions (H × W × D) 430 × 732 × 15 mm
Product weight (each) 22.8 kg
Shipping weight (each) 27.2 kg
Grill material Cloth grille with pin/cup retention
Frameless grill dimensions (H × W × D) 430 × 732 × 15 mm
Product weight (each) 22.8 kg
Shipping weight (each) 27.2 kg
Grill material Cloth grille with pin/cup retention
